A810312110019 High performance pin Excavator Bucket pin Suitable for SANY 215

>> The Company's Main Product Display

SANY pin and bushing
OEM	NAME	OEM	NAME	OEM	NAME
11954088	PIN	14501324	PIN	11975455	BUSHING
A810312110021	PIN	14327798	PIN	A820202002975	BUSHING
12344208	PIN	A810303990035	PIN	11751558	BUSHING
11972669	PIN	A820301020461	PIN	A820202002972	BUSHING
13623374	PIN	A810312110015	PIN	11967354	BUSHING
13124497	PIN	A810312110019	PIN	60065325	BUSHING
13982405	PIN	14327797	PIN	60201101	BUSHING
11795851	PIN	14327781	PIN	60201102	BUSHING
A810312110014	PIN	13887021	PIN	60201104	BUSHING
11696987	PIN	A810303990032	PIN	A820202003320	BUSHING
11856384	PIN	13562518	PIN	11744971	BUSHING
A810312110017	PIN	14173258	PIN	10989145	BUSHING
11954086	PIN	14173260	PIN	11016612	BUSHING
11972607	PIN	150988000148A	BUSHING	13624387	BUSHING
11972528	PIN	150988000193A	BUSHING	11644425	BUSHING
A820202003321	PIN	150988000192A	BUSHING	11306936	BUSHING
A810303990033	PIN	14034760	BUSHING	A820202002974	BUSHING
14327796	PIN	A820202003323	BUSHING	A820202002973	BUSHING
A810303990037	PIN	61010752	BUSHING	A820202003017	BUSHING
13039467	PIN	61010753	BUSHING	11216201	BUSHING
13562517	PIN	14039205	BUSHING

    Excavator bushing

    Excavator pin

    Loader bushing

    Loader pin

    Construction machinery pins and bushings

>> Partial Applicable Vehicle Model Display

>> Premium Materials for Durability and Strength

• High-quality carbon structural steel

• 45 steel: It is a medium carbon steel with high strength and hardness. After appropriate heat treatment, such as quenching and tempering (quenching + high temperature tempering), it can obtain good comprehensive mechanical properties, and the strength, toughness and wear resistance are well balanced. It can meet the use requirements of excavator bucket pins under general working conditions, and the cost is relatively low, and it is widely used.

• Alloy structural steel

• 40Cr: This is the most commonly used alloy structural steel with good hardenability. After quenching and tempering, it can obtain higher strength, toughness and fatigue resistance than 45 steel. It is used in excavator bucket pins and can withstand greater loads and impact forces. It is suitable for working conditions with relatively harsh working conditions and high requirements for component performance.

• 42CrMo: It is an ultra-high strength alloy structural steel with high strength, high toughness and good hardenability. Its comprehensive mechanical properties are better than 40Cr. It performs well in excavator bucket pin applications that bear heavy loads, high stresses and require good fatigue resistance, and can adapt to high-intensity operation requirements under extreme conditions such as mining.

• Bearing steel

• GCr15: is a commonly used high carbon chromium bearing steel with high hardness, wear resistance and contact fatigue strength, good dimensional stability and corrosion resistance. When used for excavator bucket pins, it can maintain good performance under high load and frequent friction working conditions, reduce wear and deformation, and extend service life. It is especially suitable for occasions with extremely high requirements for pin shaft precision and wear resistance.

A810312110019 High performance pin Excavator Bucket pin Suitable for SANY 215

• Raw material preparation

• Material selection: According to the performance requirements of the product, select suitable steel, such as 40Cr, 42CrMo and other alloy structural steel or GCr15 bearing steel, etc. Ensure that the raw materials have good chemical composition and mechanical properties and meet relevant standards and specifications.

• Inspection: Strict inspection of purchased steel, including appearance inspection, dimension measurement, chemical composition analysis, hardness test, etc., to ensure the quality of raw materials.

• Cutting: According to the size and weight requirements of the bucket pin, use cutting equipment (such as sawing machine, flame cutting machine, plasma cutting machine, etc.) to cut the steel into suitable blanks. When cutting, consider the processing allowance to ensure that subsequent processing can meet the dimensional accuracy requirements.

• Machining

• Rough machining: Rough machining of the forged blank, including turning the outer circle, end face, drilling, milling keyway and other processes, remove most of the allowance, and leave a processing allowance of 0.5mm-1mm for subsequent finishing. Rough machining can improve processing efficiency and reduce processing costs.

• Finishing: Use high-precision lathes, grinders, milling machines and other equipment for finishing to ensure that the dimensional accuracy and surface roughness of the bucket pin meet the design requirements. For example, cylindrical grinding can control the dimensional accuracy within ±0.01mm and the surface roughness reaches Ra0.8-Ra1.6μm.

• Thread processing: If the bucket pin has a threaded part, use a thread lathe or CNC machining center for thread processing to ensure the accuracy and quality of the thread.

• Pre-surface treatment processing: According to needs, some special processing may also be performed, such as knurling, chamfering, etc., to meet assembly and use requirements.

• Heat treatment

• Quenching: Heat the machined bucket pin to above the critical temperature, keep it warm for a certain period of time, and then cool it rapidly to make the steel obtain martensitic structure and improve hardness and strength. The quenching heating temperature is generally between 820℃-860℃, and the cooling medium can be selected from water, oil or other quenching media according to the material and performance requirements.

• Tempering: The bucket pin needs to be tempered after quenching to eliminate quenching stress, stabilize the structure and size, and improve toughness. The tempering temperature is usually between 550℃-650℃. The tempering time is determined according to the specific performance requirements, generally 1-3 hours.

• Surface quenching: For some bucket pins with high requirements for surface hardness and wear resistance, surface quenching treatment may also be performed, such as induction quenching, flame quenching, etc., so that the surface has high hardness and good wear resistance, while the core still maintains good toughness.

• Surface treatment

• Hard chrome plating: Hard chrome plating can form a hard, wear-resistant and corrosion-resistant chrome layer on the surface of the bucket pin, improve the surface hardness and finish, reduce the friction coefficient, and effectively prevent wear and corrosion. The thickness of the hard chrome plating layer is generally between 0.02mm-0.05mm.

• Blackening treatment: Blackening treatment is to form a black oxide film on the surface of the bucket pin, which mainly plays the role of rust prevention and beauty. The thickness of the oxide film is generally between 0.5μm-1.5μm.

• Phosphating treatment: Phosphating treatment can form a layer of phosphate chemical conversion film on the surface of the bucket pin, which can improve the corrosion resistance, wear resistance and lubricity of the parts, and is conducive to subsequent assembly and use. The thickness of the phosphating film is generally between 1μm-10μm.

FAQs

Q1: What is the typical lifespan of the Custom Steel Excavator Pin for Hitachi 200?
A1: Our hardened excavator pins are built for extended durability, offering high performance over time with proper maintenance.

Q2: Do you offer Custom Excavator Pins for other Hitachi models?
A2: Yes, we specialize in custom steel pins for a range of Hitachi models. Contact us to get the perfect match for your equipment.

Q3: How does the hardened steel pin shaft improve excavator performance?
A3: The hardened steel pin shaft enhances wear resistance and load-bearing capacity, improving performance in demanding construction and mining operations.

Q4: Can your Custom Excavator Pins be used for both construction and mining?
A4: Our custom steel pins are designed to handle heavy-duty tasks across industries such as construction, mining, and earth-moving.

Q5: How do I place a bulk order for the Custom Steel Excavator Pin?
A5: Get in touch with us for bulk orders, and we will provide a personalized quote and production timeline for your custom pin shafts.

Q6: What quality control measures do you implement for Custom Excavator Pins?
A6: Our custom pins go through rigorous quality control, ensuring strict adherence to specifications, material standards, and durability for optimal performance.

Q7: Can I choose specific materials for the Custom Steel Pin?
A7: Yes, we offer various materials such as 45C, 41Cr4, and 42CrMo4, allowing you to select the ideal material for your excavator pin requirements.

Q8: How can I ensure the Custom Steel Excavator Pin fits my Hitachi equipment perfectly?
A8: Our custom steel pins are made to precise dimensions, and we offer tailored solutions to guarantee a perfect fit for your Hitachi 200 excavator.
